Film Faced Plywood

Film faced Meranti plywood

Film faced Meranti plywood for intensive formwork and technical applications

Film faced Meranti plywood is a formwork panel made from 100% tropical hardwood (Meranti), designed for professional applications requiring high mechanical strength, good stability and multiple reuse cycles. Coated on both sides with an AICA phenolic film, it provides a smooth surface, good performance in humid conditions and durability suited to intensive use.

Delivery subject to stock availability.
Free pick up in our warehouse at Zottegem.
Shipping within Europe possible.

Available dimensions and thickness
- Available formats: 2500 × 1250 mm
- Thicknesses: 9 / 12 / 15 / 18 / 21 mm
Qualities
- Species: Meranti (Shorea spp.) – tropical hardwood
- Dense multi-layer structure with high mechanical stability
- Two sides coated with brown AICA phenolic film (120 g/m²)
- Smooth surface suitable for formwork and technical applications
- Phenolic bonding (WBP) for use in humid conditions
Applications
- Suitable for intensive formwork applications (infrastructure works, formwork systems, prefabrication)
- Suitable for technical uses such as moulds, transport and industrial applications
- 100% Meranti structure ensuring high mechanical strength and multiple reuse cycles
- AICA phenolic film providing a clean and consistent concrete finish
- Versatile panel suitable for demanding site environments
Technical specifications
- Film quality: A/A – 120 g/m²
- Bonding quality: EN 314-2 / Class 3 (WBP – exterior phenolic bonding)
- Application class: EN 636-3S
- Density: approx. 639 kg/m³ (indicative range 600–680 kg/m³)
- Density tolerance: approx. ±10%
- Moisture content: approx. 10%
- Dimensional tolerances: according to EN 315
- Formaldehyde emission: EN 717-2 / E1
- Fire class: D-s2, d0
- 2022_DOP_VSB043_Indo_Meranti_film_EN_2022-11-28-103635_onjq.pdf
